• Giant Talon 24 2024

Giant Talon 24 2024

$469.00 $549.00
Colour

Loading locations...
Shop online or in store today for the Giant Talon 24 2024.

TECHS & FEATURES

×

This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

ONE SIZE
A SEAT TUBE LENGTH (mm)
270
B SEAT TUBE ANGLE
72.0°
C TOP TUBE LENGTH (mm)
520
D HEAD TUBE LENGTH (mm)
120
E HEAD TUBE ANGLE
70.0°
F FORK RAKE (mm)
34.5
G TRAIL (mm)
75.4
H WHEELBASE (mm)
971.1
J BOTTOM BRACKET DROP (mm)
40
K STACK (mm)
535.6
L REACH (mm)
346
M STAND OVER HEIGHT (mm)
547
O STEM LENGTH (mm)
60
P CRANK LENGTH (mm)
140
Q WHEEL SIZE
24"
HANDLEBAR
Giant kids tapered, alloy, 31.8mm
PEDALS
Platform
SADDLE
Explora Jr.
SEATPOST
Alloy, 27.2mm
STEM
Forged alloy Ahead, 10-degree
BOTTOM BRACKET
Semi-cartridge
BRAKE LEVERS
Alloy, junior MTB
BRAKES
Alloy, linear pull
CASSETTE
14x34
CHAIN
KMC HV500
CRANKSET
Alloy, 32t, 140mm
FRONT DERAILLEUR
N/A
REAR DERAILLEUR
Shimano Tourney
SHIFTERS
Shimano REVOSHIFT, 1x7
FORK
Custom Suspension, 50mm
FRAME
ALUXX-grade aluminium
EXTRAS
Bell, kickstand, fender, rear derailleur protector
HUBS
Nutted, 28h
RIMS
Giant Kids 24, alloy
SPOKES
Stainless, 14g
TYRES
Giant Junior Sport 24x1.95
