Giant TCR Advanced Pro 0 Disc AR 2024

$5,899.00 $8,299.00
Colour
Size
Loading locations...

CLIMB, CORNER AND DESCEND WITH GREATER SPEED, MORE CONTROL AND MAXIMUM EFFICIENCY. FROM THE MOUNTAINS TO THE FLATS, IN ALL CONDITIONS, THIS LIGHTWEIGHT COMPOSITE ROAD RACER TAKES YOU TO THE NEXT LEVEL.




KEY PERFORMANCE FACTORS





Class-leading efficiency

Combining best-in-class stiffness-to-weight with strategically placed aero tube shaping, this frameset is engineered for faster climbing, explosive acceleration and unyielding pedaling stiffness for race-winning performance.


Advanced aerodynamics

This is where the TCR's most quantifiable gains can be found compared to previous generation models. Every tube shape was analyzed, engineered and tested to create an overall structure with significantly lower drag at a wider range of yaw angles.




Total control

Integrated disc brakes deliver smooth, powerful stopping power and modulation for added control in variable weather and road conditions. Flat mount brakes and thru-axles boost stiffness and improve overall handling, while added frame and fork clearance allows for larger diameter tyres up to 32mm.

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

XS
S
M
ML
L
XL
XS
S
M
ML
L
XL
A SEAT TUBE LENGTH (mm)
425
445
470
500
530
560
B SEAT TUBE ANGLE
74.5°
74.0°
73.5°
73.0°
73.0°
72.5°
C TOP TUBE LENGTH (mm)
520
535
550
565
580
600
D HEAD TUBE LENGTH (mm)
120
130
145
165
185
200
E HEAD TUBE ANGLE
71.0°
72.3°
73.0°
73.0°
73.0°
73.0°
F FORK RAKE (mm)
45
45
45
45
45
45
G TRAIL (mm)
72.1
64
59.2
59.2
59.2
59.2
H WHEELBASE (mm)
976
977
980
991
1006
1020
I CHAIN STAY LENGTH (mm)
405
405
405
405
405
405
J BOTTOM BRACKET DROP (mm)
72
70
70
67
67
67
K STACK (mm)
517
528
545
562
581
596
L REACH (mm)
376
383
388
393
402
412
M STAND OVER HEIGHT (mm)
706
725
747
773
800
816
O STEM LENGTH (mm)
80
90
100
110
110
120
P CRANK LENGTH (mm)
170
170
172.5
172.5
175
175
Q WHEEL SIZE
700C
700C
700C
700C
700C
700C
