• Liv STP 24 FS

Liv STP 24 FS

$829.00 $929.00
Colour
Loading locations...

TRAIL-READY CONTROL FOR YOUNG SHREDDERS.

The Liv STP 24 FS 2024 is built for adventurous young riders who are ready to level up their skills. With full suspension, grippy tyres, and a low standover height, this fun and capable bike handles jumps, drops and rough terrain with confidence and control.

Key Performance Factors

Full Suspension Confidence

A 100mm suspension fork and rear shock provide better traction and smoother control across rough trails, helping young riders gain confidence.

Kid-Friendly Geometry

A lightweight ALUXX aluminium frame with a low standover height makes it easy to manoeuvre, mount, and stop — especially on technical terrain.

TECHS & FEATURES

×

ALUXX ALUMINIUM TECHNOLOGY

This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

ONE SIZE
A SEAT TUBE LENGTH (mm)
300
B SEAT TUBE ANGLE
73.0°
C TOP TUBE LENGTH (mm)
495
D HEAD TUBE LENGTH (mm)
105
E HEAD TUBE ANGLE
69.0°
F FORK RAKE (mm)
42
G TRAIL (mm)
79.4
H WHEELBASE (mm)
978
I CHAIN STAY LENGTH (mm)
410
J BOTTOM BRACKET DROP (mm)
30
K STACK (mm)
524
L REACH (mm)
335
M STAND OVER HEIGHT (mm)
668
O STEM LENGTH (mm)
40
P CRANK LENGTH (mm)
140
Q WHEEL SIZE
24"
GRIPS
Giant Junior
HANDLEBAR
Giant Sport, alloy, 31.8mm
PEDALS
Platform
SADDLE
STP JR
SEATPOST
Alloy, two-bolt, 30.9mm
STEM
Forged alloy, 0-degree
BOTTOM BRACKET
Cartridge
BRAKE LEVERS
Tektro HD-J285
BRAKES
Tektro HD-J285, hydraulic
BRAKES ROTOR
[F]160mm, [R]160mm rotors
CASSETTE
microSHIFT Acolyte, 12x42
CHAIN
KMC Z8.3
CRANKSET
Alloy forged, 30t, 140mm
REAR DERAILLEUR
microSHIFT Acolyte
SHIFTERS
microSHIFT Acolyte, 1x8
FORK
SR XCT L24, coil, 80mm, lockout
FRAME
ALUXX-Grade aluminium
HUBS
Giant Disc, 28h, QR, alloy, disc
RIMS
Giant 24 inch, alloy
SPOKES
Stainless, 14g
TYRES
Kenda Karma, 24x2.2
