Giant Revolt Advanced 2 2025

$3,199.95 $3,699.00
Size
Loading locations...

For those who like their gravel riding fast and free, this lightweight composite flyer lets you choose your objective: Pin on a number and go for the win, or chart a weekend adventure and discover how far you can go. With its composite frame, adjustable wheelbase, and internal storage to carry your essentials, the Revolt Advanced is ready for anything.

KEY PERFORMANCE FACTORS

Fast and Versatile

The Advanced-grade composite frame and fork offer lightweight efficiency and precise control. A flip chip in the rear dropout lets you adjust the wheelbase for quicker handling or added tyre clearance (up to 53mm) and stability. Choose between the included D-Fuse seatpost or a 30.9mm round/dropper post to tailor your ride.

Tuned Compliance

Dropped seatstays and small-diameter tubing help absorb road vibrations across rough gravel. The Contact SL XR D-Fuse alloy handlebar and carbon D-Fuse seatpost provide added comfort and control over long distances.

Smart Integration

Internally routed cables keep the cockpit clean and aero, while an internal storage compartment in the top tube makes it easy to carry tools and essentials. Integrated mounts on the frame and fork allow for easy setup of fenders or bikepacking gear, and new frame protection keeps things quiet and safe on rugged rides.

TECHS & FEATURES

×

ADVANCED COMPOSITE TECHNOLOGY

Giant’s High Performance Grade raw carbon material is used to produce this custom frame material in our own composite factory with a high stiffness-to-weight ratio. The front triangle of these framesets is assembled and moulded as one continuous piece in a proprietary manufacturing process called Modified Monocoque Construction.

×

D-FUSE TECHNOLOGY

The D-Fuse seatpost and handlebar were designed to function as a system, absorbing road shocks and vibrations so you can ride further, faster.absorbing road shocks and vibrations so you can ride further, faster.

READ MORE

×

Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

×

TUBELESS SYSTEM

Fewer flat tyres. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.

READ MORE

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

XS
S
M
ML
L
XL
XS
S
M
ML
L
XL
ASEAT TUBE LENGTH (mm)
430
450
470
490
510
530
BSEAT TUBE ANGLE
74.0°
73.5°
73.5°
73.0°
73.0°
73.0°
CTOP TUBE LENGTH (mm)
540
550
560
575
585
600
DHEAD TUBE LENGTH (mm)
125
135
150
165
185
205
EHEAD TUBE ANGLE
70.0°
71.0°
71.5°
72.0°
72.0°
72.0°
FFORK RAKE (mm)
50
50
50
50
50
50
GTRAIL (mm)
78
72
68
65
65
65
HWHEELBASE (mm)
1024
1034
1030
1036
1045
1066
ICHAIN STAY LENGTH (mm)
425
425
425
425
425
425
JBOTTOM BRACKET DROP (mm)
80
81
81
81
80
80
KSTACK (mm)
556
570
585
599
618
639
LREACH (mm)
381
387
389
391
397
407
MSTAND OVER HEIGHT (mm)
724
731
747
764
790
814
OSTEM LENGTH (mm)
50
60
70
80
90
100
PCRANK LENGTH (mm)
170
170
172.5
172.5
175
175
QWHEEL SIZE
700c
700c
700c
700c
700c
700c
BARTAPE
Stratus Lite 3.0
HANDLEBAR
Giant Contact XR D-Fuse, 31.8mm XS:42cm, S:42cm, M:44cm, M/L:44cm, L:46cm, XL:46cm
SADDLE
Giant Approach
SEATPOST
Giant D-Fuse, composite, 14mm offset
STEM
Giant Contact AeroLight, -10 degree XS:50mm, S:60mm, M:70mm, M/L:80mm, L:80mm, XL:90mm
BOTTOM BRACKET
FSA BB-AL86, press fit
BRAKE LEVERS
Shimano GRX RX-610 hydraulic
BRAKES
Shimano GRX RX-410 hydraulic
BRAKES ROTOR
Giant MPH rotors [F]160mm, [R]160mm
CASSETTE
Shimano CS-HG710, 12-speed, 11x36
CHAIN
KMC X12L-1
CRANKSET
FSA Omega Modular AGX+, 32/48 XS:170mm, S:170mm, M:172.5mm, M/L:172.5mm, L:175mm, XL:175mm
FRONT DERAILLEUR
Shimano GRX RX-820
REAR DERAILLEUR
Shimano GRX RX-820
SHIFTERS
Shimano GRX RX-610, 2x12
FORK
Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
FRAME
Advanced-grade composite, 12x142mm thru-axle, disc, flip chip dropout, down tube storage
EXTRAS
Tubeless prepared, 53mm max tyre size in long flip chip position, 45mm max tyre size in short flip chip position, in-frame storage bag
HUBS
Giant alloy, 12mm thru-axle
RIMS
Giant P-X2 Disc wheelset, alloy
SPOKES
Sapim
TYRES
Giant CrossCut Grip (Tan) or Maxxis Rambler TR (Black), 700x40c, tubeless
