Liv Intrigue Advanced Pro 29 2

$4,136.00 $6,799.00
Colour
Size
Loading locations...

BUILT TO COVER GROUND, MOW OVER TECHY SINGLETRACK, AND CHARGE DOWN AGGRESSIVE TERRAIN, THE INTRIGUE ADVANCED PRO 29 PREFERS THE ROWDY SIDE OF LIFE.

KEY PERFORMANCE FACTORS

Top Performance Trail

Advanced-Grade Composite frame, carbon wheelset, Maestro Suspension and flip chip adjustable frame geometry equip you with a lightweight, versatile trail bike.

Balanced Agility

Obstacle-eating 29-inch wheels offer smooth handling and roll easily over small roots and rocks.

Custom Tuned Suspension

The 125 mm of Maestro Suspension has been custom tuned by women, for women to provide optimal performance for the rider and the bike’s intended use, resulting in improved traction and control.

TECHS & FEATURES

×

ADVANCED COMPOSITE TECHNOLOGY

Liv’s High-Performance Grade raw carbon material is used to produce this frameset in our own composite factory. Using state-of-the-art materials and manufacturing techniques, Liv’s Advanced-Grade Composite frames are designed to offer light weight and stiffness with optimal compliance.

×

MAESTRO SUSPENSION TECHNOLOGY

Four strategically positioned pivot points and two linkages all work together to create a single floating pivot for the most active, efficient and independent suspension system on the trail.

READ MORE

×

OVERDRIVE

Designed to provide precise front-end steering performance, this fork steerer tube technology uses oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

×

POWERCORE

A massively oversized bottom-bracket/chainstay area features a fully integrated, 86-millimeter wide bottom-bracket design (92-millimeterwide for off-road bikes). Asymmetric chainstays provide additional stiffness on the driveside and stability on the non-driveside.

×

TUBELESS SYSTEM

Engineered with proprietary Dynamic Balanced Lacing technology, this tubeless ready composite WheelSystem delivers superior efficiency, pinpoint control and comfort.

×

FLIP CHIP

The flip chip allows riders to quickly adjust the geometry of their Maestro-equipped mountain bike to better suit how and where they ride. It lets riders change the headtube/seattube angles and bottom bracket height via eccentric (offset, two-position) hardware located on the upper rocker arm.

READ MORE

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

One Size
ONE SIZE
ASEAT TUBE LENGTH (mm)
315
BSEAT TUBE ANGLE
73.0°
CTOP TUBE LENGTH (mm)
485
DHEAD TUBE LENGTH (mm)
125
EHEAD TUBE ANGLE
70.0°
FFORK RAKE (mm)
40
GTRAIL (mm)
81.9
HWHEELBASE (mm)
929
ICHAIN STAY LENGTH (mm)
385
JBOTTOM BRACKET DROP (mm)
30
KSTACK (mm)
482
LREACH (mm)
338
MSTAND OVER HEIGHT (mm)
525
OSTEM LENGTH (mm)
60
PCRANK LENGTH (mm)
152
QWHEEL SIZE
24"
SIZES
S, M, L
COLOURS
Fanatic Teal / Carbon / Chrome
FRAME
Advanced-Grade Composite front and rear triangles, 125mm Maestro Suspension, flip chip
FORK
Fox 34 Float Rhythm, 140mm, GRIP damper, Boost, 15x110, Kabolt, tapered, 44mm offset, custom tuned for Liv
SHOCK
Fox Float DPS Performance 185/50, custom tuned for Liv
HANDLEBAR
Giant Contact TR35, alloy, 35mm
GRIPS
Liv Supera, single lock ring
STEM
Giant Contact SL, 35mm S:50mm, M:50mm, L:50mm
SEATPOST
TranzX travel-adjustable dropper, remote
SADDLE
Liv Sylvia SL
PEDALS
Platform
SHIFTERS
Shimano SLX M7100, 1x12
FRONT DERAILLEUR
N/A
REAR DERAILLEUR
Shimano SLX M7100
BRAKES
Shimano M6120, hydraulic, Shimano RT-66 rotors [F]203mm, [R]180mm
BRAKE LEVERS
Shimano Deore BL-M6100
CASSETTE
Shimano SLX M7100, 10x51
CHAIN
KMC X-12
CRANKSET
Shimano MT511, 30t S:170mm, M:170mm, L:170mm
BOTTOM BRACKET
Shimano, press fit
RIMS
Giant TRX-2 Carbon 29 WheelSystem
HUBS
Giant TRX-2 Carbon 29 WheelSystem
SPOKES
Giant TRX-2 Carbon 29 WheelSystem
TIRES
[F] Maxxis Minion DHF 29x2.5WT, 3C Max Terra, EXO, TR, tubeless; [R] Maxxis Dissector 29x2.4WT, 3C Max Terra, EXO, TR, tubeless
EXTRAS
Tubeless prepared, max tyre size 2.5", max chainring size 32t
WEIGHT
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
