Liv Pique Advanced Pro 29 2023

$6,499.00

Colour

Fanatic Teal

Size

LARGE

Product variants

Loading locations...

geometry

specs

highlights

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorised dealer to determine the correct size.
Available sizes may vary from country to country.

A SEAT TUBE LENGTH (mm)

390

406

445

482

B SEAT TUBE ANGLE

74.0°

C TOP TUBE LENGTH (mm)

565

580

595

610

D HEAD TUBE LENGTH (mm)

100

110

E HEAD TUBE ANGLE

68.5°

F FORK RAKE (mm)

G TRAIL (mm)

92.9

H WHEELBASE (mm)

1100

1115

1131

1147

I CHAIN STAY LENGTH (mm)

438

J BOTTOM BRACKET DROP (mm)

K STACK (mm)

578

583

587

597

L REACH (mm)

399

413

427

439

M STAND OVER HEIGHT (mm)

693

703

726

753

O STEM LENGTH (mm)

P CRANK LENGTH (mm)

165

170

175

Q WHEEL SIZE

29"

Sizes

XS, S, M, L

Colours

Fanatic Teal/Dark Green/Chrome

Frame

Advanced-Grade Composite front and rear triangles, 100mm Maestro Suspension

Fork

Fox 32SC Float Performance, 100mm, GRIP damper, Boost 15x110 Kabolt, tapered, 44mm offset, custom tuned for Liv

Shock

Fox Float DPS Performance 165/45, custom tuned for Liv

Handlebar

Giant Contact SLR XC 35

Grips

Liv Supera, single lock ring

Stem

Giant Contact SL XC

Seatpost

Giant Contact Switch dropper, remote

Saddle

Fi'zi:k Vento Argo R5

Pedals

Platform

Shifters

Shimano Deore M6100, 1x12

Front Derailleur

N/A

Rear Derailleur

Shimano Deore M6100, Shadow +

Brakes

Shimano MT500, hydraulic, Shimano RT-56 rotors [F]180mm, [R]160mm

Brake Levers

Shimano MT-401

Cassette

Shimano Deore M6100, 10x51

Chain

KMC X-12

Crankset

Praxis Cadet, alloy chain ring 30t

Bottom Bracket

Praxis, press fit

Rims

Giant XCR 2 Carbon 29 WheelSystem

Hubs

[F] Giant MTB alloy, 6-bolt, [R] Giant MTB alloy, 3-pawl driver, 6-bolt

Spokes

Sapim

Tyres

[F] Maxxis Recon Race, 29x2.25", foldable, TLR, EXO, tubeless [R] Maxxis Recon Race, 29x2.25", foldable, TLR, EXO, tubeless

Extras

Tubeless prepared, max tyre size 2.25", max chainring size 32t

Weight

The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.

KEY PERFORMANCE FACTORS

Fast

A light and stiff Advanced-Grade Composite frame and wheelset maximises your power and efficiency, especially noticeable on climbs.

Capable

29-inch wheels easily roll over small obstacles, while 100mm of Maestro suspension – tuned for women, by women – help absorb rougher trails.

Stable

An integrated dropper seatpost and clearance for up to 2.4-inch tyres means you can confidently ride moderately technical terrain.
