• Giant Cross City 1 Disc 2022

Giant Cross City 1 Disc 2022

$939.00 $1,249.00
Colour
Size

Loading locations...
Shop online or in store today for the 1 Disc 2022 Giant Cross City.

TECHS & FEATURES

×

This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

×

Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

×

D-FUSE TECHNOLOGY

The D-Fuse seatpost and handlebar were designed to function as a system, absorbing road shocks and vibrations so you can ride further, faster.absorbing road shocks and vibrations so you can ride further, faster.

READ MORE

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

S
M
L
XL
S
M
L
XL
A SEAT TUBE LENGTH (mm)
430
485
535
585
B SEAT TUBE ANGLE
73.5°
73.0°
73.0°
73.0°
C TOP TUBE LENGTH (mm)
565
580
595
610
D HEAD TUBE LENGTH (mm)
115
130
160
190
E HEAD TUBE ANGLE
70.0°
71.0°
71.0°
71.0°
F FORK RAKE (mm)
50
50
50
50
G TRAIL (mm)
76
69.4
69.4
69.4
H WHEELBASE (mm)
1074
1075
1091
1107
I CHAIN STAY LENGTH (mm)
445
445
445
445
J BOTTOM BRACKET DROP (mm)
60
60
60
60
K STACK (mm)
538
556
585
613
L REACH (mm)
406
410
416
423
M STAND OVER HEIGHT (mm)
714
754
799
842
O STEM LENGTH (mm)
90
90
100
100
P CRANK LENGTH (mm)
170
170
175
175
Q WHEEL SIZE
700C
700C
700C
700C
GRIPS
Giant Connect Ergo
HANDLEBAR
Giant Sport XC, 31.8mm
SADDLE
Giant Sport
SEATPOST
Giant D-Fuse, alloy
STEM
Giant Sport, 15-degree, 31.8mm S:90mm, M:90mm, L:100mm, XL:100mm
BOTTOM BRACKET
Shimano SM-BB52
BRAKE LEVERS
Shimano
BRAKES
Tektro HD-R280
BRAKES ROTOR
Giant MPH rotors [F]160mm, [R]160mm
CASSETTE
Shimano CS-HG200, 11x36
CHAIN
KMC X9 with Missing Link
CRANKSET
Shimano MT-210, 30/46 S:170mm, M:170mm, L:175mm, XL:175mm
FRONT DERAILLEUR
Shimano Acera
REAR DERAILLEUR
Shimano Alivio
SHIFTERS
Shimano Altus, 2x9
FORK
Advanced-Grade Composite, composite OverDrive steerer, disc
FRAME
ALUXX-Grade Aluminium, disc
EXTRAS
45mm max tyre size
HUBS
Alloy, 28h
RIMS
Giant double wall aluminium
SPOKES
Stainless, 14g
TYRES
Giant S-X2, puncture protect, 700x38c
