• Giant Talon 29 1 2025

Giant Talon 29 1 2025

$1,199.00 $1,399.00
Colour
Size

Loading locations...

KEY PERFORMANCE FACTORS

Modern MTB Design
Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control
New geometry is optimised for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tyres (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable
All-new ALUXX aluminium frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

TECHS & FEATURES

×

This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

SIZING GUIDE AND GEOMETRY

Sizing to be used as a reference only. Please check with a local authorized dealer to determine the correct size.
Available sizes may vary from country to country.

S
M
L
XL
S
M
L
XL
A SEAT TUBE LENGTH (mm)
380
420
450
480
A1 SEAT POST INSERTION DEPTH (mm)
340
200
237
292
B SEAT TUBE ANGLE
74.5°
74.5°
74.5°
74.5°
C TOP TUBE LENGTH (mm)
581
604
629
653
D HEAD TUBE LENGTH (mm)
95
105
125
140
E HEAD TUBE ANGLE
67.5°
67.5°
67.5°
67.5°
F FORK RAKE (mm)
44
44
44
44
G TRAIL (mm)
108.9
108.9
108.9
108.9
H WHEELBASE (mm)
1139
1164
1191
1217
I CHAIN STAY LENGTH (mm)
455
455
455
455
J BOTTOM BRACKET DROP (mm)
55
55
55
55
K STACK (mm)
597
606
625
639
L REACH (mm)
415
436
456
476
M STAND OVER HEIGHT (mm)
715
709
709
710
O STEM LENGTH (mm)
50
60
70
80
P CRANK LENGTH (mm)
170
170
170
175
Q WHEEL SIZE
29
29
29
29
HANDLEBAR
Giant Connect Trail, 31.8mm
PEDALS
MTB caged
SADDLE
Giant ErgoContact Trail
SEATPOST
Giant Contact Switch Core dropper, remote S: 100mm travel / 30.9 x 350mm M: 120mm travel / 30.9 x 400mm L: 120mm travel / 30.9 x 400mm XL: 120mm travel / 30.9 x 400mm
STEM
Giant Sport, 7-degree S: 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29)
BOTTOM BRACKET
Cartridge
BRAKE LEVERS
Tektro TKD143
BRAKES
Tektro TKD143, hydraulic
BRAKES ROTOR
Tektro rotors [F]180mm, [R]160mm
CASSETTE
Shimano CUES, CS-LG300, 11x48
CHAIN
KMC X-11
CRANKSET
ProWheel Charm, 30t (29) S: 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29)
FRONT DERAILLEUR
N/A
REAR DERAILLEUR
Shimano CUES, U6000, Shadow+
SHIFTERS
Shimano CUES SL-6000, 1x10
FORK
SXC32-2 RL, air spring, Boost 15x110, alloy steerer S: 100mm travel (29) M: 100mm travel (29), L: 100mm travel (29) XL: 100mm travel (29)
FRAME
ALUXX-grade aluminium, disc
SHOCK
N/A
EXTRAS
2.4 inch max tyre size, 32t max chainring size
FRONT HUB
15x110 thru axle
HUBS
Alloy, sealed bearing
REAR
12x142 thru-axle
RIMS
Giant GX03V 29 alloy, double wall
SPOKES
Stainless, 14g
TYRES
Maxxis Rekon Race 29x2.4, wire bead
